Product view
Volume Correctors
Converts line-condition volume into the standard-condition figure you invoice on.
The ME-V continuously measures line pressure and gas temperature, computes compressibility from stored composition and applies the correction to the meter's pulse stream in real time. It stores hourly and daily archives alongside an event log, so the entire billing period is reconstructable.
Features
- •Full PTZ correction with stored gas composition
- •Hourly and daily archives with event logging
- •Battery-powered, up to five-year field life
- •Optical and Modbus interfaces for readout
- •Sealed metrological parameters for fiscal service
Key features
- Full PTZ correction with stored gas composition
- Hourly and daily archives with event logging
- Battery-powered, up to five-year field life
- Optical and Modbus interfaces for readout
- Sealed metrological parameters for fiscal service
Applications
- Custody-transfer correction
- Industrial billing meters
- District station measurement
Technical specifications
Confirmed against your duty at order stage — send us the operating conditions and we will verify the selection.
| Parameter | Value |
|---|---|
| Correction | PTZ per standard compressibility algorithms |
| Pressure range | 0.8 – 100 bar absolute |
| Temperature range | −25 °C to +60 °C |
| Accuracy | Better than ±0.5 % of computed volume |
| Power | Internal battery, up to 5 years |
| Enclosure | IP66, ATEX II 1G option |
Technical documents
Datasheets, installation manuals, drawings and conformity declarations.
- ME-V Volume Corrector — Technical DatasheetDatasheet · PDF · on request
- ME-V Volume Corrector — Installation & Maintenance ManualManual · PDF · on request
- ME-V Volume Corrector — Dimensional DrawingDrawing · DWG / PDF · on request
- ME-V Volume Corrector — Declaration of ConformityCertificate · PDF · on request
Documentation for Volume Correctors is issued on request against the confirmed specification. Request the document pack.
Related products
Enquire about this product
The more detail you give on the duty, the more precise the proposal comes back.
Frequently asked questions
What engineers most often ask when specifying this equipment.
It follows the flow profile. Wide turndown with low minimum flow favours rotary; high, steady flow favours turbine on cost; internal consumption monitoring that needs no fiscal approval is best served by a quantometer. Send us a load profile and we will size against it.
