Product view
Servomotors
Drives the air and gas dampers that hold combustion ratio across the firing range.
The BC-SM actuator positions air and gas dampers to a signal from the burner controller, holding the air/gas ratio correct as firing rate changes. A mechanical position indicator and adjustable cam or electronic curve let the ratio be set and re-checked at commissioning without guesswork.
Features
- •Proportional positioning across the full firing range
- •Visible position indicator
- •Adjustable mechanical cam or electronic characterisation curve
- •Manual override for commissioning
- •Torque suited to damper and butterfly-valve duty
Key features
- Proportional positioning across the full firing range
- Visible position indicator
- Adjustable mechanical cam or electronic characterisation curve
- Manual override for commissioning
- Torque suited to damper and butterfly-valve duty
Applications
- Air/gas ratio control on forced-draught burners
- Damper and butterfly-valve positioning
- Industrial ovens, dryers and boiler plant
Technical specifications
Confirmed against your duty at order stage — send us the operating conditions and we will verify the selection.
| Parameter | Value |
|---|---|
| Supply voltage | 230 V AC / 24 V AC-DC |
| Torque | Model dependent, sized to damper duty |
| Running time | Adjustable, typically 30 – 120 s full stroke |
| Control signal | 3-point step or 0–10 V / 4–20 mA |
| Enclosure | IP54 |
| Operating temperature | −20 °C to +60 °C |
Technical documents
Datasheets, installation manuals, drawings and conformity declarations.
- BC-SM Servomotor — Technical DatasheetDatasheet · PDF · on request
- BC-SM Servomotor — Installation & Maintenance ManualManual · PDF · on request
- BC-SM Servomotor — Dimensional DrawingDrawing · DWG / PDF · on request
- BC-SM Servomotor — Declaration of ConformityCertificate · PDF · on request
Documentation for Servomotors is issued on request against the confirmed specification. Request the document pack.
