Burner Controller
Product view
Burner Controller
Sequences ignition, proving and safety interlocks into one supervised start-up.
The BC-CTRL programmer runs the burner through purge, pilot, main-flame and proving stages in a fixed sequence, holding the process at each step until the previous one is confirmed. Ignition transformer timing, valve opening and flame-proving all run under its supervision, so a fault at any stage produces a lockout instead of a burner running through an unconfirmed step.
Features
- •Fixed start-up sequence: pre-purge, pilot, main flame, run
- •Supervises ignition transformer and gas valve timing
- •Lockout on flame-failure or sequence fault with diagnostic indication
- •Manual or automatic reset options
- •Drop-in replacement for standard burner programmer footprints
Key features
- Fixed start-up sequence: pre-purge, pilot, main flame, run
- Supervises ignition transformer and gas valve timing
- Lockout on flame-failure or sequence fault with diagnostic indication
- Manual or automatic reset options
- Drop-in replacement for standard burner programmer footprints
Applications
- Burner start-up sequencing
- Retrofit of ageing burner programmers
- Industrial ovens, dryers and boiler plant
Technical specifications
Confirmed against your duty at order stage — send us the operating conditions and we will verify the selection.
| Parameter | Value |
|---|---|
| Supply voltage | 230 V AC / 110 V AC |
| Safety time | 3 s or 10 s (model dependent) |
| Outputs | Ignition, pilot valve, main valve, fault relay |
| Lockout indication | LED fault code |
| Enclosure | IP40 |
| Operating temperature | −20 °C to +60 °C |
Technical documents
Datasheets, installation manuals, drawings and conformity declarations.
- BC-CTRL Burner Controller — Technical DatasheetDatasheet · PDF · on request
- BC-CTRL Burner Controller — Installation & Maintenance ManualManual · PDF · on request
- BC-CTRL Burner Controller — Dimensional DrawingDrawing · DWG / PDF · on request
- BC-CTRL Burner Controller — Declaration of ConformityCertificate · PDF · on request
Documentation for Burner Controller is issued on request against the confirmed specification. Request the document pack.
Related products
Burner Equipments
Servomotors
Drives the air and gas dampers that hold combustion ratio across the firing range.
Gas Pressure Regulators
R Series – Gas Pressure Regulator, Threaded Connection PS: 16 bar
Direct-acting, spring-loaded regulation with threaded connections, rated PS 16 bar.
Enquire about this product
The more detail you give on the duty, the more precise the proposal comes back.
Frequently asked questions
What engineers most often ask when specifying this equipment.
Ionisation probes are simpler and cheaper and work well on stable, well-defined gas flames with a good earth path. UV cells suit larger flames, oil/gas dual-fuel duty and installations where the probe cannot be positioned reliably.
